Fiio New K3 2021 Desktop DAC and Amplifier

Fiio New K3 2021 Desktop DAC and Amplifier:



Flagship-grade ES9038Q2M DAC Chip

FiiO New K3 is equipped with Flagship-grade ES9038Q2M DAC Chip, supports 32-Bit/384kHz PCM and DSD256 decoding. The signal-to-noise ratio has increased by 14dB and distortion has reduced by 14dB

High-Performance OPAMP

FiiO New K3 is with high-performance OPAMP, has noticeably improved on various performance indicators and overall sound quality.

ADC Volume Control

FiiO New K3 is with low and high gains ADC Volume control.

USB Type-C Power

The new K3 adopts the modern USB Type-C input interface for a more reliable and stable connection, including that of power. However, care to ensure an uncompromised power supply doesn't stop there - the new K3 implements overvoltage protection (OVP) and a double-filter circuit to ensure power supply stability, while the digital and analog audio circuits each get their own power supply to greatly
reduce crosstalk.

Technical Parameters

• XMOS XU208 USB Chip.
• ES9038Q2M DAC.
• LPF: Ti OPA1612.
• AMP: OPA926x2.
• Max sampling rate: PCM 32-Bit/384kHz, DSD256(USB), PCM 32-Bit/192khz, DSD64(Coaxial), PCM 24-Bit/96kHz(Optical).
• Output Power: Up to 200mW Bal(32ohm), Up to 114mW PO(32ohm).
• SNR: 121dB PO and LO, 120dB Bal.
• Noise Floor: </=4uV PO, </=6uV Bal, </=3uV LO.
• Recommended Headphone Impedance: 16ohm-150ohm.
